Campsite 36RF Floorplan

Hitch Weight
2,375 lb.
GVWR
15,388 lb.
UVW
12,588 lb.
CCC
2,800 lb.
Exterior Length
42' 9"
Exterior Height
13' 6"
Exterior Width
96"
Fresh Water
49 gal.
Gray Water
76 gal.
Black Water
38 gal.
Awning Size
11' &15'

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.



  • Standard features:

    • Campsite Culinary Workstation Sink
    • X9 TITAN Chassis
    • ULTRARIDE Suspension
    • Helux™ Coil-Cushion Pin Box
    • Cool Stream Dual 18K Furrion Zone A/C System
    • Infinity Flow On-Demand Hot Water
    • Aluminum Alloy Wheels
    • Pure Source Total Water Filtration System
    • Clean Sweep Black Tank Rinse System
    • Vista View Glass Entry Door
    • Arctic Guard Heated & Enclosed Underbelly
    • Campsite Chef Outdoor Kitchen Setup
    • Flex Mount Accessory Hitch
    • Mocktastic Fan Turbo Ventilation System
    • Electric Fireplace
    • Ever Clean No Carpet Zone Seamless Flooring
    • Sky Scene Panoramic Opening Window System
    • Hide Away Waste Station
    • Clean Dock Robot Vacuum Bay
    • Luma Trim Accent Lighting
    • Step Stash Entry Cubby
    • Paw Pantry Pet Dining Spot
    • Quick Chef Built-In Air Fryer & Convection Microwave
    • True Bake Full-Size Culinary Range
    • Pro Pantry Deep Storage System
    • Sure Stride Stable Steps All-Terrain Entry
    • Stone Style Solid Surface Countertops
    • 55” Smart TV
    • Volt Port USB-C Charging Network
    • Dream Suite Camp King Bed Sleep System
    • Campsite CineSuite Bedroom Cinema Projector
    • Extra Bedroom Storage:
    • Wash Ready Stackable Laundry Bay
    • Hideaway Hive Bunk Storage System
    • BasinPro Comfort Vanity
    • Rain Spa 48” Glass Shower Enclosure:
    • Porcelain Toilet
    • Max Store Intelligent Storage Design
    • Vault MaxPass-Thru Basement:
    • Campsite Cargo Crate:
    • 400-Watt Solar Charging System
    • Rear Sight Wireless View Assist
    • Bin Guard Integrated Trash Compartment:
    • Safeway Flush Upper Deck
    • Mirror-Tinted, Solar-Reflective Windows
    • Outdoor TV Entertainment
    • Towing Package (3000lb tow rating)
