Cherokee 27RR Floorplan

The private 11’ garage includes a dinette that converts into 2 twin beds. Outside amenities include a full outside kitchen plus shower, speakers, TV hook up and rear ramp converting into a patio for entertaining. Inside features a dinette slide out and includes a large skylight and chef’s kitchen with black stainless steel farm sink and sink cover for additional counter space. The bedroom has a queen bed and nearby bathroom includes a full size sink, medicine cabinet and shower/tub combination.

Hitch Weight
1,058 lb.
GVWR
9,985 lb.
UVW
6,738 lb.
CCC
3,247 lb.
Exterior Length
34' 0"
Exterior Height
10' 6"
Exterior Width
96"
Fresh Water
52 gal.
Gray Water
38 gal.
Black Water
38 gal.
Awning Size
15'

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.



  • Limited Package

    • 12 V, High Efficiency, 10 Cubic Foot Residential-Style Refrigerator with Travel Lock
    • Chef Select Black Stainless Steel Kitchen Suite Package
    • Super Kitchen
    • Seamless Countertops
    • Matte Black Heavy Duty Spring Assisted Kitchen Faucet Sprayer
    • Residential Farm Style Black Stainless Steel Sink
    • Fireplace (Where Available)
    • Premium Bedding and Comforter
    • Upgraded Sofa with Bolster Arm Rests
    • Supersized Central Air Conditioning Unit 15,000 BTU (Where Available)
    • USB-C Charging Stations
    • Full Hybrid Tub with Shower Surround
    • LED Interior Lights
    • Light Filtering Sheet Shading Premium Blackout
    • Zebra Blinds
    • RV King Bed (Where Available)
    • Bedside Inverter
    • Exclusive Solar Thermo Controlled Reflective Tinted Safety Glass Windows
    • Blackout Glass, Safety Slam, Friction Hinge Entry Door with Window and Shade Prep
    • Cherokee Exclusive Stable Step with Oversized Landing
    • Exterior LED Light Strip at Awning
    • External Porch Scare Light
    • Outside Kitchen (Where Available)
    • Premium Wheel Package
    • Tire Pressure Indicators
    • Spare Tire
    • Four Stabilizer Jacks
    • Ladder Prep
    • Cherokee Backup Camera System
    • 12 Volt Tank Heaters
    • Ramp Door Patio System (Toyhauler Models Only)
    • Removable Gaucho Brackets (Toyhauler Models Only)
    • Moonshade (Toyhauler Models Only)
    • Adventure Package: Aggressive Off-road Tires, Diamond Plated Exterior & Lifted Frame (Toyhauler Models Only)
    • Juice Pack: 200W Roof Mounted Solar Panel, 30Amp Solar Charger, Volt Meter & Battery Disconnect
    • Power Gear Frame Technology and Space Saver Rail Design
    • 5/8" Tongue and Groove Plywood Flooring
    • Seamless Roof Membrane with Heat Reflectivity-Walkable

  • Base Camp Package

    • Black Waste Tank Flush Out Kit
    • Armored Underbelly Tank Enclosure
    • Large Exterior Folding Assist Grab Handle
    • Outdoor Shower with Hot and Cold Water
    • Outside TV Bracket and Hookups
    • Power Awning
    • RV Grill Quick Connect

  • Campfire Package

    • 40" Dinette Drawers x 2 on Models with Slide Outs
    • Tankless Water Heater
    • Cabinets in Bedroom
    • High Output Attic Fan in Bathroom
    • Air Fryer
    • Roof Mounted Ducted Air Conditioner (N/A on Models Under 26')
    • Skylight over Shower
    • Solid Bedroom Doors (Where Available)
    • Skylight over Shower
    • Solid Bedroom Doors (Where Available)
