388WDM - DSO

Hitch Weight
2,115 lb.
GVWR
18,115 lb.
UVW
13,144 lb.
CCC
4,971 lb.
Exterior Length
41' 6"
Exterior Height
13' 5"
Exterior Width
96"
Fresh Water
57 gal.
Gray Water
82 gal.
Black Water
82 gal.
Awning Size
TBD

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.



  • ADVANTAGE PACKAGE (Mandatory Features)

    • Cedar Creek's Famous All Aluminum Superstructure – 16" on Centers or Less True Gelcoat, Painted, Front Cap
    • True" High Gloss Gelcoat Exterior (The Best of the Best in Exteriors)
    • Vegatouch Control Panel and Firefly Dimmer Switches with Wireless Connectivity to Your Phone
    • 4'x6' ABS Removeable Underbelly Panels
    • Extra Wide Friction Entry Door
    • Heated Storage Compartment with Diamond Tread Flooring
    • Dexter Nev-R-Adjust Brakes
    • Road Armor™ Suspension with Wet Bolts and Bronze Bushings
    • TST™ Tire Pressure Monitoring System
    • 12V Heating Pads on all Tanks
    • Automatic 6-Point Hydraulic Leveling System
    • Mid-Ship Turn Signals
    • New Ultra Slim, Rear Brake Lights
    • MorRyde® Power Easy Reel
    • 200 Watt Go Power Solar Panel
    • Deep Cell Battery

  • CONVENIENCE PACKAGE

    • 5-Tier MorRyde® Easy-Steps™
    • 2" Bike Rack Receiver (N/A 371FL, 385TH)
    • Slam Latch Baggage Doors with Magnetic Catches
    • Animal Leash Latch
    • 12 Gallon LP/110V Hot Water Heater with Bypass Kit
    • (2) Air Conditioners with Dual Zone Control
    • King WiFi Router/Range Extender
    • USB Ports Throughout
    • Prepped for an Optional Washer and Dryer
    • InterVac Central Vacuum System with Front Storage Compartment Port and Interior Automatic Dustpan
    • Solid Surface Countertops with Stainless Steel Under-mounted Sinks
    • Free Standing 24" Gas Range
    • Smart Television with Swing Arm in Living area
    • Bluetooth Connectivity Speaker
    • Deluxe Day/Night Roller Shades (Night Shades in Bedroom Only)
    • 20 Cu. Ft. Stainless Steel Refrigerator with Icemaker and dedicated inverter
    • Variable Speed, Power Fan with Rain Sensor override in Kitchen area
    • New Decorative Shower head in the Bathroom

  • STANDARD FEATURES EXTERIOR

    • 3M® Bonded Sidewalls – resilient, with outstanding resistance to UV, heat, cold, moisture, oils, gasoline, highway chemicals. Creates a bond that grows stronger with age and resists delamination
    • 21,000 Lb. Rhino Box Hitch
    • Z-frame with Metal Wrapped Skirting to the Frame
    • Hehr Frameless, Tinted Automotive Style Windows
    • Lionshead Special Trailer (ST) Tires with "No Excuses" One Year Guarantee!
    • Full, Walk-on Roof with Alpha-Ply TPO Membrane with Lifetime warranty
    • Electric Awning with Upgraded Fabric and LED Night Lights
    • Quick Disconnect Exterior LP Gas Connection
    • Full Docking Station with Multi-function Tank Levers, Outside Shower, Black Tank Flush, 12V Battery Disconnect Door Side, Cold Water Port
    • Mini Outdoor Kitchen area with Mini Fridge and Slide Out Grill (375BHO, 377BH Only)
    • One Year of Saferide™ RV Roadside Assistance
    • Free Membership to Forest River Owners Group (F.R.O.G.)

  • STANDARD FEATURES ELECTRONICS

    • 32" Television in the Bedroom
    • (2) Exterior Satellite and Cable Hook-ups to Bedroom and Living Room
    • Prewired for Satellite to the Roof
    • Prewired for Rear camera

  • STANDARD FEATURES KITCHEN AND LIVING AREA

    • Two Tone Cabinet Doors and Fascia in Kitchen and Living Room
    • LED Lighting Fixtures
    • Murphy Pantry
    • Residential, High Top, Swivel, Kitchen Faucet with Pull-out Sprayer
    • Stainless Steel, 30" Over the Range Microwave Oven
    • Full Panel Back splashes (Where applicable)
    • Natural Satin Free Standing Table with (4) Chairs (2 Folding /2 stationary with hidden storage)
    • Vinyl Floor Covering
    • Hide-a-Bed Sofa (where applicable)
    • Power Theater seating with USB Ports (where applicable)
    • Decorative Fireplace with Natural Wood Mantel

  • STANDARD FEATURES BATHROOM

    • Full 48" x 30" Rectangular Shower with Large Seat and Sliding Glass Doors
    • Large Single or Double Faucet Sinks with White Cabinetry
    • Skylight Over the Shower
    • Upgraded Shower Head
    • 18" High Porcelain Toilet with Top Circular Flush System
    • Create-A-Breeze Circulation Fan
    • Convenient Wall Switches for Fan and Lights
    • Extra Storage for Linens
    • LED Night Lighting Under the Vanity

  • STANDARD FEATURES BEDROOM

    • Black-out Night Shades (Bedroom only)
    • Individual Reading Lighting Above the Bed
    • USB Plug-ins on Each Side of the King Bed
    • Standard 72" x 80" King Bed (N/A 385TH)
    • Flip-Up Dresser Top with Hidden Storage
    • Storage Area Under the Bed

  • OPTIONAL FEATURES EXTERIOR

    • 21,000 Lb. Curt™ Air Ride Hitch
    • Dual Pane Frameless, Tinted Windows *included Champagne Package
    • Furrion Rear Observation or (4) Camera Security Systems
    • Slide-out Awning Toppers
    • 12' THULE® Power Awning on Dining Slide (N/A 371FL, 385TH)
    • Heat Pump on Main Air Conditioner
    • Truma™ On-Demand Hot Water System *included Champange Package
    • Full Body Paint Package
    • LP Generator Prep * included Champagne Package
    • 5.5K Onan Marquis Gold LP Generator with Prep
    • King, Roof Mounted Satellite – My Dish RV Flexible Programming Including Local Channels

  • OPTIONAL FEATURES KITCHEN

    • 16.2 cu ft, 12vt. Refrigerator
    • 30" Convection/Microwave
    • Dishwasher in the Island (N/A 385TH, 371FL)

  • OPTIONAL FEATURES BEDROOM

    • Upgraded Luxury King Bed (N/A 385TH)
    • Upgraded Luxury Queen Bed
    • Optional Side-by-Side Washer/Dryer
    • Cadet Wall Mounted Heater with Circulation Fan

  • CHAMPAGNE PACKAGE

    • Disc Brakes
    • Rear Fiberglass Cap (N/A 371FL, 385TH)(*extends unit 10")
    • Generator Prep
    • Truma™ On Demand Water Heater
    • Safe
    • Upgraded Mattress
    • Upgraded Bedroom Package
    • Macerator Toilet
    • Champagne Graphic Package
    • Upgraded Island Lighting
    • 3rd AC
    • Upgraded Vegatouch "Eclipse" Module with Multiplex System Capabilities
    • Wood Lambrequins
    • Remote entry lock
    • Dual Pane Windows

  • OFF THE GRID" POWER PACKAGES - LITHIUM 200X PACKAGE

    • (2) 100 Ah MasterVolt Ultra 12/1250 1.25 kWh Li Batteries
    • Combimaster 12/2000-100 120V Inverter/Charger
    • EasyView 5" touchscreen
    • Masterbus USB Interface
    • 400watts Go Power Solar
    • MPPT 30 Solar Controller

  • OFF THE GRID" POWER PACKAGES - 460XL POWER PACKAGE

    • (1) 460 Ah Mastervolt Ultra 12/6000 Li Battery
    • Combi Master 12-3500 200A 120V Inverter/Charger
    • EasyView 5" Touchscreen
    • Masterbus USB Interface
    • 800watts Go Power Solar
    • MPPT Solar ChargeMaster 60
