Rockwood Extreme Sports Package Camping Trailers

WELCOME TO THE ROCKWOOD EXTREME SPORTS PACKAGE (ESP), a camper designed for active couples and families. Whatever the preference; mountain biking, canoeing, paddle boarding or surfing, the ESP camping trailers are designed to allow you to make the most of your outdoor experience.

BUILT FOR 21ST CENTURY CAMPING. The ESP package has interior features targeted for the modern, active lifestyle including a Digital Media Receiver with Bluetooth, MP3 player, USB and auxiliary ports, WiFi Ranger WiFi Booster, recharging station with (2) additional USB ports, LED interior lighting and more.

Filter

Select filters below and then click the Filter Results button to remove non-matching Floorplans and their Specifications
















to

to




Specifications

Print


Hitch Weight:
UVW:
CCC:
Exterior Open Length:
Exterior Closed Height:
Exterior Closed Length:
Exterior Width:
Box Size:
178 lb.
1722 lb.
656 lb.
17' 1"
5' 11"
12' 1"
84"
8.00'
254 lb.
2180 lb.
724 lb.
20' 4"
5' 11"
17' 1"
84"
10.00'
234 lb.
2076 lb.
808 lb.
20' 1"
5' 11"
15' 4"
84"
10.00'
338 lb.
2559 lb.
1279 lb.
23' 10"
6' 2"
19' 2"
84"
12.00'
294 lb.
2933 lb.
861 lb.
26' 5"
6' 2"
22' 5"
84"
12.00'
221 lb.
3377 lb.
1844 lb.
30' 8"
6' 2"
26' 8"
84"
12.00'
325 lb.
2428 lb.
1397 lb.
19' 2"
5' 8"
19' 2"
84"
12.00'
290 lb.
2272 lb.
1518 lb.
19' 0"
5' 11"
19' 0"
84"
12.00'
346 lb.
2392 lb.
1454 lb.
22' 1"
5' 11"
22' 1"
84"
12.00'
302 lb.
2604 lb.
1198 lb.
20' 10"
5' 11"
20' 10"
84"
14.00'

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Features & Options

Print
  • One Piece Vacuum Bonded Fiberglass Roof with Metal Interior Ceiling
  • 3-Stage Double Arm Lifter Posts
  • Lower Door Operational in Closed Position
  • Five Piece Sectionalized Hurculite Supreme Tenting
  • Tent Permanently Attached on Bunk Ends and Slide Out
  • Plywood Bunk Ends W/1000 LB Weight Rating
  • Full Perimeter Aluminum Bed Frames
  • Easy Glide Scissor Pole Bed Supports
  • Powder Coated Rafter Poles and Bed Bows
  • Tinted Vinyl Windows
  • One Piece Undercoated Structure Wood Floor
  • E- Coated Tubular Steel Frame
  • (4) E-Z Crank-Down Stabilizer Jacks w/ Sand Pads
  • Under Floor 20 Gallon Fresh Water Tank
  • 2000 lb. Tongue Jack w/ Swivel Wheel
  • 7-Way Pigtail Plug
  • WiFi Ranger WiFi Booster SKY 4
  • Slatewood Interior
  • Wood Look Flooring
  • “Leather Appearance” Seating
  • Electric Water Pump
  • Hot Water Package (Std. 2280BHESP, 232ESP, 282TESP Only)
  • Port-A-Potty (1910ESP Only)
  • Spray Away Utility Hose, Hot & Cold with Hot Water Package
  • Antifreeze Inlet to Bypass Fresh Water Tanks When Winterizing
  • Permanently Mounted Indoor Range w/Cover
  • 3 Way Fridge 1.9 cu. ft.
  • Residential Style Cabinet Doors
  • Wood Drawers w/ Full Extension Metal Guides
  • Swing Galley w/Storage
  • USB Charging Ports
  • Digital Media Receiver w/ AM/FM Stereo, Bluetooth, MP3 Player, USB & Aux. Ports
  • TV Outlet with Cable and Satellite Hook Up
  • 30 Amp Detachable Power Cord w/ Storage Bag
  • 25 Amp Converter w/ Built in Battery Charger (1640ESP Only)
  • 35 Amp Converter w/ Built in Battery Charger
  • Three Speed Ventilation Fan
  • Ceiling LED Lights and Jacks for Accessories (Tent Campers)
  • 1 Bunk LED Light with Fan
  • LED Bunk Light In Slide Outs (Select Floorplans)
  • LP Leak/Carbon Monoxide Detector
  • Storage Net Over Bunks
  • Quilted Top Bed Mattresses
  • Thermostatically Controlled Heated Mattresses
  • Leaf-Spring Axle
  • Easy Lube Axles
  • 15” Mud Rover Radial Tires, Aluminum Wheels (Std. 1910ESP, 1970ESP, 1640ESP, 2280BHESP, 232ESP, 282TESP Only) (Note: Dual Axle 282TESP)
  • Electric Brakes
  • 28.5” Front Storage Deck w/ 200 # Weight Capacity (2280BHESP Only)
  • 54” Frt. Storage Deck w/ 650 # Wt. Capacity (232ESP Only)
  • 105” Front Storage Deck w/ 1300 # Weight Capacity (282TESP Only)
  • ProRac Systems Permanent Mount Cross bars
  • Power Lift System (Select Floorplans)
  • Built-in A-Frame Mounting Provision for Equalizer Hitch Bar Installation
  • Double Battery Box and Wiring Kit
  • Solar Panel Prep on Frame
  • 20 lb. LP Bottle
  • Dual 20 lb. LP Bottles with Cover and Automatic LP Regulator (Std. 232ESP, 282TESP, 2280BHESP Only)
  • Chrome Diamond Plated Front and Side Skirt
  • Awning
  • LED Under Awning Light Strip
  • Outdoor Gas Grill w/ Worktable
  • Outside Speaker
  • Courtesy Light on Front (2280BHESP, 232ESP, 282TESP Only)
  • One Piece Screen Door
  • Folding Grab Handle (N/A 1640ESP)
  • Exterior Graphic Design
  • Shower and Cassette Toilet Package Incl. Cabinet w/Shower, Cassette Toilet and Shower Curtain. (Opt. 2280BHESP)
  • Hanging Pantry
  • Air Conditioner Wiring Kit
  • 20k BTU Forced Air Furnace w/ Electric Ignition
  • (4) Bike Rack (Select Floorplans)
  • ProRac Systems Upright Bike Carrier
  • ProRac Systems Kayak Carrier
  • ProRac Systems Load Stops
  • ProRac Systems Tie Downs
  • 40 Watt Solar Panel
  • Screen Room w/ Privacy Panels
  • Hot Water Package (Incl. Water Filter, Outside Shower, Six Gallon DSI Hot Water Heater, Demand Water Pump)
  • Steel Air Conditioner Reinforcing Laminated Into Roof
  • Privacy Curtains
  • Roof Valances
  • Patio Light
  • 110V Exterior Outlet
  • Double Door Step
  • Spare Tire
  • Spare Tire Cover
  • Spare Tire Bracket
  • Water Filter
  • Outside Shower
  • Six Gallon DSI Hot Water Heater
  • Demand Water Pump
