Rockwood Camping Trailers

Freedom Series

MAKING YOUR INVESTMENT GO A LONG WAY. Rockwood takes pride in packing the most value possible into our Freedom series. Finding the perfect fit for the specific needs of your active family is made easier by the wide variety of floor plans available. While each model comes standard with many features, you still have flexibility to incorporate as many options as you choose to fit your camping preferences.

High Wall Series

KISS THE CAMPGROUND BATH HOUSE GOODBYE. WELCOME TO THE ROCKWOOD HIGH WALL SERIES. We have designed this series for the camping family who wants the refinement of larger vacationing units in a light-weight camper. Ample counterspace, upgraded appliances, convenient pull-up curtains providing a wide view of the surroundings and tasteful interiors make this camper a gorgeous option to experience.

Filter

Select filters below and then click the Filter Results button to remove non-matching Floorplans and their Specifications


















to

to




Specifications

Print


Hitch Weight:
UVW:
CCC:
Exterior Open Length:
Exterior Closed Height:
Exterior Closed Length:
Exterior Width:
Box Size:
162 lb.
1465 lb.
793 lb.
17' 1"
5' 4"
12' 1"
84"
8.00'
195 lb.
1608 lb.
683 lb.
20' 1"
5' 4"
14' 5"
84"
10.00'
230 lb.
1997 lb.
1233 lb.
20' 1"
5' 6"
15' 4"
84"
10.00'
255 lb.
1896 lb.
1359 lb.
20' 1"
5' 6"
15' 4"
84"
10.00'
263 lb.
2439 lb.
824 lb.
23' 10"
5' 6"
5' 6"
84"
12.00'
295 lb.
2654 lb.
641 lb.
23' 9"
6' 0"
18' 10"
84"
12.00'
360 lb.
2854 lb.
506 lb.
25' 9"
6' 0"
19' 1"
84"
14.00'
380 lb.
3334 lb.
546 lb.
25' 9"
6' 7"
19' 3"
84"
14.00'
371 lb.
3721 lb.
1278 lb.
27' 9"
6' 9"
21' 3"
84"
16.00'
289 lb.
2278 lb.
1011 lb.
23' 10"
5' 6"
17' 3"
84"
12.00'
292 lb.
2795 lb.
497 lb.
23' 9"
5' 9"
18' 10"
84"
12.00'
297 lb.
2698 lb.
599 lb.
23' 9"
5' 9"
18' 10"
84"
12.00'
386 lb.
2955 lb.
431 lb.
23' 9"
5' 9"
18' 10"
84"
12.00'
370 lb.
2831 lb.
539 lb.
25' 9"
5' 9"
19' 2"
84"
14.00'
296 lb.
3249 lb.
547 lb.
25' 9"
6' 7"
19' 3"
84"
14.00'

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Features & Options

Print
  • One Piece Vacuum Bonded Fiberglass Roof with Metal Interior Ceiling
  • Steel Air Conditioner Reinforcing Laminated Into Roof (1640LTD, 1940LTD, HW277, HW269 Only)
  • 3-Stage Double Arm Lifter Posts
  • Lower Door Operational in Closed Position
  • Five Piece Sectionalized Hurculite Supreme Tenting
  • Tent Permanently Attached on Bunk Ends and Slide Out
  • Plywood Bunk Ends W/1000 LB Weight Rating
  • Full Perimeter Aluminum Bed Frames
  • Easy Glide Scissor Pole Bed Supports (N/A 1640LTD, 1940LTD Only)
  • Powder Coated Rafter Poles and Bed Bows
  • Tinted Vinyl Windows
  • One Piece Undercoated Structure Wood Floor
  • E- Coated Tubular Steel Frame
  • Rear Crank Down Stabilizer Jacks w/ Sand Pads (1640LTD, 1940LTD Only)
  • (4) E-Z Crank-Down Stabilizer Jacks w/ Sand Pads (N/A 1640LTD, 1940LTD Only)
  • 11 Gallon Fresh Water Tank (1640LTD, 1940LTD Only)
  • Under Floor 20 Gallon Fresh Water Tank (N/A 1640LTD, 1940LTD Only)
  • 12 Gallon Gray Water Holding Tanks (HW277, HW269 Only)
  • 12 Gallon Black Water Holding Tank (HW277, HW269 Only)
  • 2000 lb. Tongue Jack w/ Swivel Wheel
  • 7-Way Pigtail Plug
  • WiFi Ranger WiFi Booster SKY 4 (HW277, HW269 Only)
  • Slatewood Interior
  • Wood Look Flooring
  • “Leather Appearance” Seating
  • Stainless Steel Look Appliances and Sink (HW277, HW269 Only)
  • Electric Water Pump
  • Hot Water Package (Opt 1980; Std 1950, 2318G, 2514F, 2716F, HW277, HW269 Only)
  • Port-A-Potty (2514F Only)
  • Hard Wall Shower with Residential Flush Toilet and Monitor for Holding Tanks, Battery and Water Pump Switch (HW277, HW269 Only)
  • Antifreeze Inlet to Bypass Fresh Water Tanks When Winterizing
  • Two Burner Free-Standing Range (1640LTD, 1940LTD Only)
  • Permanently Mounted Indoor Range w/Cover (N/A 1640LTD, 1940LTD, HW277, HW269 Only)
  • Three Burner Glass Top Stove with Oven (HW277, HW269 Only)
  • Microwave (HW277, HW269 Only)
  • 110V Electric Outside Accessible Fridge (2716F Only)
  • 3 Way Fridge 1.9 cu. ft. (Std Freedom Floorplans; Opt 1640LTD, 1940LTD; N/A HW277, HW269 Only)
  • Extra Large 3 Way Fridge (HW296, HW277 Only)
  • Residential Style Cabinet Doors
  • Wood Drawers w/ Full Extension Metal Guides
  • Swing Galley w/Storage (N/A HW277, HW269 Only)
  • Large Clothes Bar (HW277, HW269 Only)
  • USB Charging Ports (N/A 1640LTD, 1940LTD Only)
  • Digital Media Receiver w/ AM/FM Stereo, Bluetooth, MP3 Player, USB & Aux. Ports (HW277, HW269 Only)
  • TV Outlet with Cable and Satellite Hook Up (N/A 1640LTD, 1940LTD Only)
  • 30 Amp Detachable Power Cord w/ Storage Bag
  • 25 Amp Converter w/ Built in Battery Charger (1640LTD, 1940LTD Only)
  • 35 Amp Converter w/ Built in Battery Charger (N/A 1640LTD, 1940LTD Only)
  • Roof Vent (1640LTD, 1940LTD Only)
  • Three Speed Ventilation Fan (N/A 1640LTD, 1940LTD Only)
  • Interior Floor Lights (HW277, HW269 Only)
  • Ceiling LED Lights and Jacks for Accessories (Tent Campers)
  • 1 Bunk LED Light with Fan (N/A 1640LTD, 1940LTD Only)
  • 2 Bunk LED Light with Fan (HW277, HW269 Only)
  • LED Bunk Light In Slide Outs (N/A 1640LTD, 1940LTD Only)
  • LP Leak/Carbon Monoxide Detector
  • Privacy Curtains (Std 1640LTD, 1940LTD Only)
  • Storage Net Over Bunks (N/A 1640LTD, 1940LTD Only)
  • Quilted Top Bed Mattresses (N/A HW277, HW269 Only)
  • Quilted Top Memory Foam Mattresses (HW277, HW269 Only)
  • Thermostatically Controlled Heated Mattresses
  • Leaf-Spring Axle (N/A HW277, HW269 Only)
  • Independent Torsion Axles (HW277, HW269 Only)
  • Easy Lube Axles (N/A 1640LTD, 1940LTD Only)
  • Spare Tire, Cover and Mount (Std 1640LTD, 1940LTD Only)
  • 12” Radial Tires (Std 1640LTD, 1940LTD Only)
  • 13” Radial Tires w/ Aluminum Wheels (N/A 1640LTD, 1940LTD, HW277, HW269 Only)
  • 14” Radial Tires w/ Aluminum Wheels (HW277, HW269 Only) (Note: Dual Axle Models HW296)
  • Electric Brakes (Opt 1640LTD, 1940LTD Only; Std all other floorplans)
  • EZ Reach Storage with Sliding Tray All Front Storage Models (Select Floorplans)
  • ProRac Systems Permanent Mount Cross bars (N/A 1640LTD, 1940LTD Only)
  • Power Lift System (Opt 1640LTD, 1940LTD Only; Std all other floorplans)
  • Built-in A-Frame Mounting Provision for Equalizer Hitch Bar Installation
  • Double Battery Box and Wiring Kit (N/A 1640LTD, 1940LTD Only)
  • Solar Panel Prep on Frame
  • 20 lb. LP Bottle (N/A HW277, HW269 Only)
  • Dual 20 lb. LP Bottles with Molded Hard Cover and Automatic LP Regulator (HW277, HW269 Only)
  • Diamond Plated Lower Front Cap (HW277, HW269 Only)
  • Awning
  • LED Under Awning Light Strip (N/A 1640LTD, 1940LTD Only)
  • Outdoor Gas Grill w/ Worktable (Opt 1640LTD, 1940LTD Only; Std all other floorplans)
  • Outside Speaker (HW277, HW269 Only)
  • Patio Light (1940LTD, HW277, HW269 Only)
  • 110V Exterior Outlet (1940LTD, HW277, HW269 Only)
  • Black Water Hose Storage (HW277, HW269 Only)
  • Solid Door / Step Combo (HW277, HW269 Only)
  • Single Entry Step (1640LTD, 1940LTD Only)
  • One Piece Screen Door
  • Folding Grab Handle (N/A 1640LTD, 1940LTD Only)
  • Exterior Graphic Design
  • Convenience Pack (Incl. Privacy Curtains, Roof Valances, A/C Bracing, Patio Light, 110V Exterior Outlet) - - O O O - -
  • Power Front Jack (HW277, HW269 Only)
  • Shower and Cassette Toilet Package Incl. Cabinet w/Shower, Cassette Toilet and Shower Curtain. (Opt. 2318G)
  • 3 Way Fridge 1.9 cu. ft. (Std Freedom Floorplans; Opt 1640LTD, 1940LTD; N/A HW277, HW269 Only)
  • Hanging Wardrobe (HW277, HW269 Only)
  • Hanging Pantry (N/A 1640LTD, 1940LTD)
  • Air Conditioner Wiring Kit
  • 13.5k BTU Low Profile Air Conditioner (Factory Installed) (HW277, HW269 Only)
  • 15k BTU Low Profile Air Conditioner (Factory Installed) (HW277, HW269 Only)
  • 20k BTU Forced Air Furnace w/ Electric Ignition
  • Electric Brakes (Opt 1640LTD, 1940LTD Only; Std all other floorplans)
  • (4) Bike Rack (Select Floorplans)
  • ProRac Systems Upright Bike Carrier (N/A 1640LTD, 1940LTD)
  • ProRac Systems Kayak Carrier (N/A 1640LTD, 1940LTD)
  • ProRac Systems Load Stops (N/A 1640LTD, 1940LTD)
  • ProRac Systems Tie Downs (N/A 1640LTD, 1940LTD)
  • Power Lift System (Opt 1640LTD, 1940LTD Only; Std all other floorplans)
  • 40 Watt Solar Panel
  • Dual 20 lb. LP Bottles with Cover and Automatic LP Regulator (N/A HW277, HW269 Only)
  • Screen Room w/ Privacy Panels
  • Outdoor Gas Grill w/ Worktable (Opt 1640LTD, 1940LTD Only; Std all other floorplans)
  • Steel Air Conditioner Reinforcing Laminated Into Roof (Std 1640LTD, 1940LTD, HW277, HW269 Only)
  • Privacy Curtains
  • Roof Valances
  • Patio Light
  • 110V Exterior Outlet
  • Single Entry Step (Double Door Step HW277, HW269 Only)
  • Spare Tire
  • Spare Tire Cover
  • Spare Tire Bracket
  • Water Filter
  • Outside Shower
  • Six Gallon DSI Hot Water Heater
  • Demand Water Pump
